DNY Air-Cooled Portable Spot Welder

The DNY air-cooled portable spot welder is light duty, flexible and easy to use. The welding process is completed using spot welding guns mounted on robotic arms and controlled digitally to maximize production efficiency and precision.

Features

A resistance welding transformer is attached to the spot welding gun, which offers easy operation.
This projection welding equipment is typically air cooled, which is a lightweight and portable unit to make quick, strong spot welds.

Parameter

Item	Unit	DNY2-10	DNY2-16	DNY2-25	DNY2-40
Rated voltage	V	380	380	380	380
Rated frequency	HZ	50/60	50/60	50/60	50/60
Rated capacity	KVA	10	16	25	40
Rated duty cycle	%	20	20	20	20
Insulation class		B	B	B	B
No-load secondary voltage	V	10.5	11.5	12.5	13.5
Extension arm length	mm	150	150	150	150
Maximum pressure	N	3900	4500	5000	5500
Stroke	mm	30	30	30	30
Air pressure	Mpa	0.5	0.5	0.5	0.5
Cooling water flow	L/min	5	5	5	5
Cable length	mm	2000	2000	2000	2000
Weight	KG	50	60	70	80

Since our establishment in 1999, Darui has been engaged in the design and production of various types of resistance welders, including spot welders, butt welders, seam welders, and more. We have the capabilities to offer you with superior custom service according to your different welding requirements. Our welding machines are widely applied in the manufacturing of home appliances, aviation equipment, electronics, automobiles, furniture, etc. We have earned the trust of customers at home and abroad.
